Airchains. Installing the node

Airchains is a powerful and flexible framework that allows you to create customized rollups with many features. The framework supports EVM, SVM and CosmWasm based development, which opens wide horizons for developers.

Minimum system requirements

• Node type: Testnet

• Processor: 4 cores

• RAM: 8 GB

• Storage: 150 GB

Node installation

Automatic installation

To simplify the process, use the automatic installation script:

wget -O airchaint https://raw.githubusercontent.com/111STAVR111/props/main/Airchains/airchaint && chmod +x airchaint && ./airchaint

Manual Installation

Server preparation

First you need to update the packages and install the required dependencies:

sudo apt update && sudo apt upgrade -y
sudo apt install curl tar wget clang pkg-config libssl-dev jq build-essential bsdmainutils git make ncdu gcc git jq chrony liblz4-tool -y

Installing Go 1.21.6

Go will need to be installed for the framework to work:

ver="1.21.6"
wget "https://golang.org/dl/go$ver.linux-amd64.tar.gz"
sudo rm -rf /usr/local/go
sudo tar -C /usr/local -xzf "go$ver.linux-amd64.tar.gz"
rm "go$ver.linux-amd64.tar.gz"
echo "export PATH=$PATH:/usr/local/go/bin:$HOME/go/bin" >> $HOME/.bash_profile
source $HOME/.bash_profile
go version

Build and Setup

The next step is to build and install the required package:

cd $HOME && mkdir -p go/bin/
wget https://github.com/airchains-network/junction/releases/download/v0.1.0/junctiond
chmod +x junctiond
mv junctiond $HOME/go/bin/
junctiond version --long | grep -e commit -e version

Now you can initialize the node:

junctiond init STAVR_guide --chain-id=junction

Creating or restoring a wallet:

junctiond keys add <walletname>

OR

junctiond keys add <walletname> --recover

Network setup

After initialization, you need to download the genesis file:

wget -O $HOME/.junction/config/genesis.json "https://raw.githubusercontent.com/111STAVR111/props/main/Airchains/genesis.json"
sha256sum $HOME/.junction/config/genesis.json

Then set the minimum gas price and configure the connections:

sed -i 's/minimum-gas-prices =.*$/minimum-gas-prices = "0.001amf"/' $HOME/.junction/config/app.toml
external_address=$(wget -qO- eth0.me)
sed -i.bak -e "s/^external_address *=.*/external_address = "$external_address:26656"/" $HOME/.junction/config/config.toml

Setting up peers:

peers="48887cbb310bb854d7f9da8d5687cbfca02b9968@35.200.245.190:26656,2d1ea4833843cc1433e3c44e69e297f357d2d8bd@5.78.118.106:26656,de2e7251667dee5de5eed98e54a58749fadd23d8@34.22.237.85:26656,1918bd71bc764c71456d10483f754884223959a5@35.240.206.208:26656,ddd9aade8e12d72cc874263c8b854e579903d21c@178.18.240.65:26656,eb62523dfa0f9bd66a9b0c281382702c185ce1ee@38.242.145.138:26656,0305205b9c2c76557381ed71ac23244558a51099@162.55.65.162:26656,086d19f4d7542666c8b0cac703f78d4a8d4ec528@135.148.232.105:26656,3e5f3247d41d2c3ceeef0987f836e9b29068a3e9@168.119.31.198:56256,8b72b2f2e027f8a736e36b2350f6897a5e9bfeaa@131.153.232.69:26656,6a2f6a5cd2050f72704d6a9c8917a5bf0ed63b53@93.115.25.41:26656,e09fa8cc6b06b99d07560b6c33443023e6a3b9c6@65.21.131.187:26656"
sed -i.bak -e "s/^persistent_peers *=.*/persistent_peers = "$peers"/" $HOME/.junction/config/config.toml

Creating and managing a service

Create a service file:

sudo tee /etc/systemd/system/junctiond.service > /dev/null <<EOF
[Unit]
Description=junction
After=network-online.target
[Service]
User=$USER
ExecStart=$(which junctiond) start
Restart=on-failure
RestartSec=3
LimitNOFILE=65535
[Install]
WantedBy=multi-user.target
EOF

Apply and Run:

sudo systemctl daemon-reload
sudo systemctl enable junctiond
sudo systemctl restart junctiond && sudo journalctl -fu junctiond -o cat

SnapShot and StateSync

Snapshot can be used to synchronize nodes, which is updated every 5 hours:

cd $HOME
sudo systemctl stop junctiond
curl -o - -L https://airchains-t.snapshot.stavr.tech/airchain-snap.tar.lz4 | lz4 -c -d - | tar -x -C $HOME/.junction --strip-components 2
sudo systemctl restart junctiond && journalctl -fu junctiond -o cat

Network state can be synchronized using StateSync:

SNAP_RPC=https://airchains.rpc.t.stavr.tech:443
SEEDS="bb26fc8cef05cee75d4cae3f25e17d74c7913967@airchains-t.seed.stavr.tech:4476"
cp $HOME/.junction/data/priv_validator_state.json $HOME/.junction/priv_validator_state.json.backup
sed -i -e "/seeds =/ s/= .*/= "$SEEDS"/"  $HOME/.junction/config/config.toml
LATEST_HEIGHT=$(curl -s $SNAP_RPC/block | jq -r .result.block.header.height);
BLOCK_HEIGHT=$((LATEST_HEIGHT - 1000));
TRUST_HASH=$(curl -s "$SNAP_RPC/block?height=$BLOCK_HEIGHT" | jq -r .result.block_id.hash)
echo $LATEST_HEIGHT $BLOCK_HEIGHT $TRUST_HASH

Useful commands and node management

Node state information:

junctiond status 2>&1 | jq .NodeInfo

View logs:

sudo journalctl -fu junctiond -o cat

Service management:

sudo systemctl restart junctiond

Managing keys and validator

Create a new key or restore:

junctiond keys add Wallet_Name

OR

junctiond keys add Wallet_Name --recover

Creating a validator:

junctiond tx staking create-validator $HOME/.junction/validator.json --from WalletName --fees 200amf --chain-id junction -y

The platform supports many useful tools and services to help you manage your node efficiently and keep it running safely.
